MINI ASI fiber optic transceiver

1-16CH ASI with Audio RS232 or Ethernet fiber optic transmitter and receiver

ASI fiber optic transmitter and receiver, ASI fiber converter, 1-64 channels CWDM uncompressed ASI fiber optic extender, ASI to fiber extender, ASI optical transceiver. ASI extender over fiber . we welcome any AV transmission OEM device
  • Product Introduction
  • MINI ASI fiber optic transmitter and receiver

    ASI fiber optic transmitter and receiver,  ASI fiber converter, 1-64 channels CWDM uncompressed ASI fiber optic extender,  ASI to fiber extender,  ASI optical transceiver.  ASI extender over fiber .   we welcome any AV transmission OEM device


    1.  Overview

    Our  MINI ASI fiber optic transmitter and receiver  could transmit 1-ch ASI , 1-ch reversed data RS485/RS422/RS232,
    optional loop out in transmitter and receiver end over one fiber, single mode or multimode. Signals are equalized and re-clocked prior to fiber optic transmission.
    The transmitter features a re-clocked and equalized ASI loop through; the receiver features two re-clocked and equalized  ASI outputs

    2.  Features

    1-channel unidirectional ASI I and 1-ch reversed RS485 optional  over single core fiber
    Compliant with the standard of DVB-ASI(EN50083-9)
    Range from 19.4Mb/s to 270Mb/s
    Auto adaption to the speed of SDI 143M,177M,270M,360M,540Mbps, or DVB-ASI
    Output wavelength 1310nm,1550nm and 16 types of CWDM (ITU-T G.694.2 compliant)
    100m automatic cable equalization, all the 2.97Gb / s rate below(Belden 1694A)
    Optional network management system
    LED status indicators monitor the critical parameters
    Support hot swap
    Stand-alone, 2U rack mount for 16 pcs of SDI fiber cards

    3.  Specifications

    a)  Serial TV, BNC input

    Signal standard: SMPTE259M,SMPTE297M,SMPTE310, SMPTE305(SDTI), DVB-ASI(EN50083-9)
    Input number: 1
    Reflection loss: >15DB
    Equilibrium: 0-200m @270Mb/s
    Connector: 75Ω BNC

    b)  Optics

    Channel: 1
    Type: single-mode (multimode optional)
    Wavelength: 1310nm /1550nm
    Reflection loss: > 15dB
    Dithering: < 0.2UI
    Connector: LC/PC

    c)  Serial TV, BNC output (EO/OE)

    Channel: 1, loop is optional
    Signal level: 800mV nominal
    Rise/fall time: 200ps indication
    Overshoot: < 10% amplitude
    Reflection loss: >15dB
    Dithering: < 0.1UI
    Connector: 75Ω BNC

    d) Data

    Channel: 1
    Data format: RS-485 (full/half duplex) and support NRZ, RZI and Manchester
    Data rate: DC to 100 Kb/s
    Mode: Full/half duplex
    Connector: wire connecting terminal

    e)  Power and environmental indication

    Operating temperature: 0°C~+50°C
    Pressure: 1A@12VDC
    Power: 12 W
    EMI/RFI: meet FCC Part 15 Class A, EU EMC standard
    Average time trouble-free: >100000 hours

    f)  Other
    Dimension: 30mm ×105mm  ×120mm
    Weight: 2Kg

    4.  Applications
    Remote OB Van/Truck Video Feeds;
    Broadcast Studio Camera Feeds;
    Long-haul Signal Transport;
    TV station/video conference;
    Lecture Hall Projector Connectivity;
    Medical/Surgical Room Broadcast;
    Small corporate campus video links

    5.   Ordering information

    ASI Fiber Optic Transmitter/Receiver
    HC2010MD-T
    1-ch ASI input, 1-ch reversed RS485, single mode, single fiber, LC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 2U rack mount
    HC2010-R

    1-ch ASI output, 1-ch reversed RS485, single mode, single fiber, LC/PC fiber connector, BNC video interface, 0-120km, stand-alone or 2U rack mount
